Regloplas - 300L/20/FM65/1K-RT100 (G-300L-0002)
Please contact us to request a price quote for Regloplas - 300L/20/FM65/1K-RT100 (G-300L-0002) , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 300L/20/FM65/1K-RT100 (G-300L-0002) by Regloplas in United Kingdom?
You can purchase 300L/20/FM65/1K-RT100 (G-300L-0002) by Regloplas from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 300L/20/FM65/1K-RT100 (G-300L-0002)?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Regloplas in United Kingdom?
While we are not the official distributor or seller of Regloplas in United Kingdom, we source our products from reliable channels and offer you original Regloplas equipment at competitive prices.
How can I access 300L/20/FM65/1K-RT100 (G-300L-0002) catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 300L/20/FM65/1K-RT100 (G-300L-0002) on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 300L/20/FM65/1K-RT100 (G-300L-0002)?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
Technical information
| Manufacturer | Regloplas |
|---|---|
| Part number | 300L/20/FM65/1K-RT100 (G-300L-0002) |
| Inner Code | 4720272 |
| Description | temperature control unit |
| Technical specification | Temperature control unit 1-circuit device Semi-open system Flow temperature max. 300°C Heat carrier oil Capacity 15.0 l Expansion space 20.0 l Heating capacity 20 kW Cooling capacity 160 kW Cooling type indirect cooling at flow temperature 280 °C at cooling water temperature 20 °C at a flow rate of 20 l/min per circuit FM65 pump type magnetic coupling pump Max. flow rate 90 l/min Pressure max. 10 bar Power consumption 2.8 kW Max. system pressure half-open system Max. flow pressure pump pressure RT100 control Measurement type Pt100 ports Forward/return flow G ¾” IG Cooling water network G ¾” Network water pressure min. 2-6 bar Protection class IP54 Ambient temperature max. 40 °C Dimensions W/H/D 432/1356/1474 mm Weight approx. 246 kg Colour grey, RAL 9006/7016 Continuous sound pressure level <70 dB (A) standard equipment - PID controller with high accuracy - SSR for wear-free heating - USB data logger for process logging as a CSV file - Dirt filter in the water network connection - Dirt filter in the system return - lockable transport wheels - internal bypass for pump protection - Analog display for system and flow pressure - Dry run protection/ level monitoring - filling nozzle for manual filling - stainless steel expansion tank - Two-stage level monitoring - without connection cable, without plug |
| Weight: | 246 |
