Regloplas - G-P180S-0001
Please contact us to request a price quote for Regloplas - G-P180S-0001 , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy G-P180S-0001 by Regloplas in United Kingdom?
You can purchase G-P180S-0001 by Regloplas from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the G-P180S-0001?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Regloplas in United Kingdom?
While we are not the official distributor or seller of Regloplas in United Kingdom, we source our products from reliable channels and offer you original Regloplas equipment at competitive prices.
How can I access G-P180S-0001 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for G-P180S-0001 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for G-P180S-0001?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
Technical information
| Manufacturer | Regloplas |
|---|---|
| Part number | G-P180S-0001 |
| Inner Code | 4988866 |
| Technical specification | P180S/8/SM23H/SK-RT100 Temperature control unit 1-circuit device pressurized water device Flow temperature max. 180°C Water heat transfer Capacity 1.0 l expansion room - Heating capacity 8 kW Cooling capacity 76 kW Cooling type indirect cooling at flow temperature 170 °C at cooling water temperature 20 °C with flow rate per circuit 20 l/min SM23H pump type leak-free magnetic coupling pump flow rate max. 40 l/min Pressure max. 5.5 bar Power consumption 0,5 kW System pressure max. 14 bar Flow pressure max. max. 20 bar RT100 control Pt100 measurement type ports Voltage 400V/50Hz/3PE Forward/return G ½” G ½” cooling water network Net water pressure min. 2-6 bar Protection class IP54 Ambient temperature max. 40 °C Dimensions W/H/D 236/589/812 mm Color grey, RAL 9006/7016 Continuous sound pressure level <70 dB (A) standard equipment - Automatic water refill - Suction - PID controller with high accuracy - SSR for wear-free heating - USB data logger for process logging as a CSV file - Dirt filter in the water supply - Dirt filter in the system return - water circuits made of stainless materials - lockable transport wheels - internal bypass for pump protection - 4m connection cable, without plug - incl. filling pump - including low-calcification precision cooling with its own cooling pump (SK) - Dry run protection/level monitoring O-MR400V50HZ voltage 400V/50Hz |
| Weight: | 52 |
