Rectus (Parker) - 21KLKS06MPN
Please contact us to request a price quote for Rectus (Parker) - 21KLKS06MPN , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 21KLKS06MPN by Rectus (Parker) in United Kingdom?
You can purchase 21KLKS06MPN by Rectus (Parker) from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 21KLKS06MPN?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Rectus (Parker) in United Kingdom?
While we are not the official distributor or seller of Rectus (Parker) in United Kingdom, we source our products from reliable channels and offer you original Rectus (Parker) equipment at competitive prices.
How can I access 21KLKS06MPN catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 21KLKS06MPN on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 21KLKS06MPN?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
Technical information
| Manufacturer | Rectus (Parker) |
|---|---|
| Part number | 21KLKS06MPN |
| Inner Code | 1866292 |
| Description | Quick coupling |
| Technical specification | Series: 21 Seal: NBR Long series: 21KL Nominal diameter in mm: 5 Nominal size area in mm²: 20 Advantages: one-handed operation. Small dimensions. Smallest, barely noticeable leakage when uncoupling. No air trap during the coupling process. Pressure range: PB = 8 bar, maximum static operating pressure (without pulsation) with min. 4x static safety. Temperature range: -20°C to +100°C (NBR) -40°C to +120/150°C (EPDM) -15°C to +200°C (FKM) 0°C to +316°C (FFKM) depending on the flow medium. Barrier: Quick coupling with low leakage shut-off on both sides Connection: bulkhead version 4 x 6 mm Connection description: bulkhead design 4 x 6 mm Connection type: screw connection Material: nickel-plated brass Material description: Brass CuZn39Pb3 2.0401 (except EH) Seal description: nitrite-butadiene rubber Surface: nickel-plated Connection material: nickel-plated brass Valve body material: nickel-plated brass Release sleeve material: nickel-plated brass Valve material: brass Spring material snap ring: stainless steel 1.4310 Balls/pins material: stainless steel 1.4034 Seal material: Perbunan® Weight in kg: 0.04 Vent coupling: No Safety lock: No One-handed operation: Yes Two-hand operation: No Ball lock: Yes Pin lock: No Ultra-FLO valve: No Vacuum-compatible: Yes Suitable for water: Yes Flat sealing: Yes Suitable for breathing/Respiratory protection: No Pressure Eliminator: No Hydraulic range: No Pneumatic range: Yes Standard product: No Mold cooling: No |
| Weight: | 0.04 |
