Dwyer - DM-1112
Please contact us to request a price quote for Dwyer - DM-1112 , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy DM-1112 by Dwyer in United Kingdom?
You can purchase DM-1112 by Dwyer from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the DM-1112?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Dwyer in United Kingdom?
While we are not the official distributor or seller of Dwyer in United Kingdom, we source our products from reliable channels and offer you original Dwyer equipment at competitive prices.
How can I access DM-1112 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for DM-1112 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for DM-1112?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
Technical information
| Manufacturer | Dwyer |
|---|---|
| Part number | DM-1112 |
| Inner Code | 1009991 |
| Description | DigiMag Differential Pressure & Flow Gauge (0-100"w.c.) |
| Technical specification | Service Air and non-combustible, compatible gases Housing Materials Glass filled plastic Accuracy ±1% FS including linearity, hysteresis and repeatability; ±2% FS for ranges 1 "w.c. and below Temperature Limits 0 to 140°F (-18 to 60°C) Compensated Temperature Limits 32 to 122°F (0 to 50°C) Long Term Stability ±1% FS per year Thermal Effect ±0.05% FS/°F typical; ±0.10% FS/°F typical for ranges 1 "w.c. and below Display 4-digit LCD (Digits: 0.60 x 0.33") Display Update Selectable for 1 second, 10 minutes or update only from button push Pressure Limits Normal and bi-directional ranges 5 "w.c. and lower = 2 psi (13.7 kPa); Normal and bi-directional ranges 10 "w.c. and higher = 11 psi (75 kPa) Selectable Engineering Units "w.c., psi, kPa, Pa, mm w.c., mBar, in Hg, mm Hg, FS (0 to 100% FS) Power Requirements 9 V battery, included, user replaceable or external power supply 9 to 24 VDC Battery Service Life Battery life depending on the Display Update setting: 150 hours (typical) if Display Update = 1 second; 9 months (typical) if Display Update = 10 minutes; 1.5 years (typical) if Display Update is disabled Battery may last up to four times longer when using lithium-based battery ULTRALIFE U9VL-J Current Consumption 5 mA maximum Electrical Connections Removable terminal block for 16 to 26 AWG Electrical Entry Cable gland for 0.114 to 0.250" (2.9 to 6.4 mm) diameter cable Process Connections 1/8" (3 mm) ID tubing Enclosure Rating NEMA 4X (IP66) |
| Weight: | 0.535 |
