Coax - VMK 10 DR-NC 1E (71816)

Please contact us to request a price quote for Coax - VMK 10 DR-NC 1E (71816) , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy VMK 10 DR-NC 1E (71816) by Coax in United Kingdom?

You can purchase VMK 10 DR-NC 1E (71816) by Coax from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the VMK 10 DR-NC 1E (71816)?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Coax in United Kingdom?

While we are not the official distributor or seller of Coax in United Kingdom, we source our products from reliable channels and offer you original Coax equipment at competitive prices.

How can I access VMK 10 DR-NC 1E (71816) catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for VMK 10 DR-NC 1E (71816) on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for VMK 10 DR-NC 1E (71816)?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Coax-VMK 10 DR-NC 1E (71816) price
4 / 5
(1)

Technical information

Manufacturer Coax
Part number VMK 10 DR-NC 1E (71816)
Inner Code 4464892
Description 3/2-Way Externally Controlled Coaxial Valve, Normally Closed
Custom code 84818079
Technical specification
  • Model: VMK 10 DR-NC 1E
  • Manufacturer: Coax
  • Type: 3/2-Way Externally Controlled Coaxial Valve
  • Function: Normally Closed (NC)
  • Nominal Diameter: DN 10
  • Connection Size: G 1/4 - G 3/4 threads
  • Pressure Range: 0-16 / 0-40 / 0-63 bar
  • Flow Rate (Kv): 2.5 m³/h
  • Media: Suitable for gaseous, liquid, highly viscous, gelatinous, pasty, and contaminated media
  • Flow Direction: Depends on pressure range
  • Switching Cycles: 680 cycles/min
  • Switching Time: Opening: 30-3000 ms; Closing: 50-3000 ms
  • Media Temperature: Up to 60°C (with direct-mounted pilot valve)
  • Ambient Temperature: Up to 50°C (with direct-mounted pilot valve)
  • Weight: 1.8 kg
  • Nominal Voltage: 24 V DC; 230 V AC (40-60 Hz)
  • Protection Class: IP65 (P54) DIN 40 050
  • Features: Externally controlled, pressure-balanced, spring return, compact design, high switching cycles, optional pilot valve and limit switches.
Weight: 2
